產(chǎn)品型號 |
公稱直徑 |
設(shè)備總高(mm) |
設(shè)備凈重(kg) |
運行載荷（kg） |
運行流量(t/h) |
|
TE-ACF-06CR/SS |
DN600 |
3500 |
300 |
1500 |
3.0~4.5 |
|
TE-ACF-08CR/SS |
DN800 |
3550 |
550 |
2600 |
5.0~7.5 |
|
TE-ACF-10CR/SS |
DN1000 |
3600 |
1400 |
5200 |
7.9~11.8 |
|
TE-ACF-12CR/SS |
DN1200 |
3700 |
1700 |
7000 |
11.3~16.9 |
|
TE-ACF-15CR/SS |
DN1500 |
3850 |
2200 |
11500 |
17.6~26.4 |
|
TE-ACF-18CR/SS |
DN1800 |
4450 |
2600 |
16000 |
25.4~38.1 |
|
TE-ACF-20CR/SS |
DN2000 |
4550 |
2900 |
18000 |
31.4~47.1 |
|
TE-ACF-22CR/SS |
DN2200 |
4650 |
3700 |
22500 |
38~57 |
|
TE-ACF-25CR/SS |
DN2500 |
4800 |
4600 |
29000 |
49~73.5 |
|
TE-ACF-28CR/SS |
DN2800 |
4950 |
5400 |
39500 |
61.5~92.2 |
|
TE-ACF-30CR/SS |
DN3000 |
5050 |
6600 |
43500 |
70.6~106 |
|
TE-ACF-32CR/SS |
DN3200 |
5200 |
7600 |
50000 |
80~120 |
